Wafer, Glass Panel Measurement System

페이지 정보

작성일 July 10, 2016

본문

1. Optical Wafer Thickness MicroGauge (OWTM)

1) Introduction
FIBERPRO OWTM can measure Thickness, TTV, LTV, Warp and Bow of various kinds of wafers which are light-reflected materials.

2) Application: Si Wafer / Sapphire Wafer / Glass Wafer / SiO2 / GaAs material manufacturing process.





[Sapphire Wafer] [Silicon Wafer] [Glass Wafer]

3) Product (Accuracy: 0.2um ~ 0.5um)
* IFP-801S: Up to 6 inch Wafer
* IFP-801: Up to 12 inch Wafer
* IFP-801L: Up to 18 inch Wafer




[IFP-801S] [IFP-801]





[Operating Video]


4) Measurement Point: Thickness/TTV/LTV/Warp/Bow/Flatness




[Measurement GUI]


** Site: http://www.fiberpro.com/eng/ds2_1_7.html?no=87&t=3

========================================================================================================

2. Optical Thickness Measurement System (OTMS)

1) Introduction
FIBERPRO OTMS uses the principle of white light interferometer-based technology and non-contact method for online or off-line thickness measurement.

2) Measurement Point: Thickness

3) Application
* Material: Si-Wafer, Sa-Wafer, Glass Wafer, SiO2, GaAS, Others
* Industry: LCD glass panel, Glass products, medical membranes, ophthalmic products,
Etc




[Glass flat panel] [Wafer, Panel] [Contact lens]

4) Product
* IFP-800-2
- Range: 50um ~ 2,000um
- Accuracy: 0.2um

* IFP-800-10
- Range: 2,000um ~ 10.0mm
- Accuracy: 1.0um


** Site: http://www.fiberpro.com/eng/ds2_1_7.html?no=102&t=3

# Contact Point
- E-mail: sales@fiberpro.com
- Phone: +82-42-360-0037
- Name: Mr. Lee, Jongbo
